单路
特点:
-通用交流输入/全范围
-小型化设计，体积紧凑，安装方便
-高可靠性：采用高可靠性的优质电解电容
-宽工作范围：-25℃至70℃
-保护功能：过载/过压/过温保护
-高效率，长寿命
-100%满负载老化测试
-低纹波噪声、低待机功耗、高效率
-满足5000m海拔应用
-符合IEC/EN/UL/BSEN62368、EN60335、EN61558、EN62477、GB4943等认证标准
| 产品 | 系列标题 | 功率 | 输入电压 (VAC) |
输入电压 (VDC) |
输出电压 | 尺寸 | 安规认证 | 规格书 | 样品申请 |
|---|---|---|---|---|---|---|---|---|---|
 |
BCU-10S▼ ▲ | 10W | 90V~264V | 100V～370V | 3.3V,5V,12V,24V | 75×68×27mm |  |
 |
 |
 |
BCU-15SL▼ ▲ | 15W | 90V~264V | 100V～370V | 3.3V,5V,12V,24V | 115×49×27mm | |
|
|
 |
BCU-25SL▼ ▲ | 25W | 90V~264V | 100V～370V | 5V,12V,15V,18V,24V,36V,48V | 79×51×28mm |  |
|
|
|
BCU-25S-B▼ ▲ | 25W | 90V~264V | 100V～370V | 5V,12V,15V,18V,24V,36V,48V | 99×51×29mm | |
|
|
 |
BCU-30S▼ ▲ | 30W | 90V~264V | 100V～370V | 5V,6.5V,8.5V,12V,15V,24V,36V,48V | 143×58×39mm | |
|
|
 |
BCU-35S▼ ▲ | 35W | 90V~264V | 100V～370V | 5V,12V,24V,36V,48V | 99×82×30mm | |
|
|
 |
BCU-40S▼ ▲ | 40W | 90V~264V | 100V～370V | 5V,12V,24V | 110×78×36mm | |
|
|
 |
BCU-45S▼ ▲ | 45W | 90V~264V | 100V～370V | 5V,8V,12V,15V,24V,30V,36V,48V | 145×78×38mm | |
|
|
 |
BCU-50S▼ ▲ | 50W | 90V~264V | 100V～370V | 5V,12V,24V,36V,48V | 99×82×30mm | |
|
|
 |
BCU-75S▼ ▲ | 75W | 90V~264V | 100V～370V | 5V,12V,15V,24V,27V,36V,48V,60V | 99×97×30mm | |
|
|
 |
BCU-100S ▼ ▲ | 100W | 90V~264V | 5V,7.5V,12V,15V,24V,27V,36V,48V,60V | 99×97×30mm | |
|
|
|
 |
BCU-150S▼ ▲ | 150W | 90V~264V | 5V,7.5V,12V,15V,24V,27V,36V,48V,60V | 129×97×30mm | |
|
|
|
 |
BCU-200S ▼ ▲ | 200W | 90V~264V | 5V,7.5V,12V,15V,24V,27V,36V,48V,60V | 159×97×30mm | |
|
|
|
|
BCU-350S▼ ▲ | 350W | 90V~264V | 5V,7.5V,12V,15V,24V,27V,36V,48V,60V | 179×99×30mm | |
|
|
|
|
BCU-450S▼ ▲ | 450W | 90V~264V | 5V,12V,15V,24V,36V,48V | 225×124×35mm | |
|
|
|
|
BCU-600S ▼ ▲ | 600W | 90V~264V | 5V,12V,15V,24V,27V,36V,48V | 225×124×41mm | |
|
|
|
|
BCU-750S▼ ▲ | 750W | 90V~264V | 5V,12V,15V,24V,27V,36V,48V,60V | 199×105×41mm | |
|
|
|
|
BCU-1000S▼ ▲ | 1000W | 90V~264V | 5V,12V,15V,24V,27V,36V,48V,60V | 230×127×41mm | |
|
|
|
|
BCU-1500S▼ ▲ | 1500W | 90V~264V | 12V,24V,36V,48V | 300×85×41mm | |
|
|
